Features
1.1. High power fiber laser cleaning.
1.2.Non-contact cleaning, no damage to workpiece
1.3.Precision positioning, selective cleaning, desired cleaning area can be applied to the workpiece.
1.4.No need chemical detergent, no consumable. Safe & environment-friendly.
1.5.Easy to operate ,Either portable or equipped with robot for automatic cleaning.
1.6.High cleaning efficiency, time-saving.
1.7.Stable laser cleaning system, free maintenance.
Applications
1.Metal surface rust removal
2.Paint cleaning
3.Oil stain, contaminant cleaning
4.Coating surface cleaning
5.Welding/Coating surface pre-treatment.
6.Stone figure surface dust & attachment cleaning.
7.Plastic mould residues cleaning
|
Model |
DP-CL1500 |
DP-CL2000 |
DP-CL3000 |
|
Power（W) |
1500W |
2000W |
3000W |
|
Power adjustment range (W) |
10-100% |
10-100% |
10-100% |
|
Cleaning head weight (KG) |
0.8KG |
0.8KG |
0.8KG |
|
Scan width (MM) |
0-150mm |
0-150mm |
0-300mm |
|
Cooling method |
Chiller |
Chiller |
Chiller |
|
Electricity |
220V |
220V |
380V |
|
Maximum power consumption (W) |
7KW |
9KW |
11KW |
|
Operating temperature (℃) |
5-35℃ |
5-35℃ |
5-35℃ |
|
Weight(KG) |
150KG |
160KG |
180KG |
|
Size (mm) |
112x68x94cm |
112x68x94cm |
122x88x115cm |
|
Cleaning efficiency: paint/floating rust 20um， |
67.5m2/h |
90m2/h |
110m2/h |
|
Cleaning efficiency: 20um greasy dirt, (m2/h) |
90m2/h |
120m2/h |
140m2/h |
|
Cleaning efficiency: titanium alloy oxide film/stainless steel weld seam (m2/h) |
40.5m2/h |
55m2/h |
70m2/h |
