CO2 laser marker is often called gas laser marker or laser engraver; CO2 laser is a gas laser whose frequency band wave length of infrared light is 10.64um. CO2 gas is filled in the discharge tube as the medium to produce laser.
Tel：+86-18565695703
Immediately consult
Feature
Laser beams of good quality, small divergence Angle, laser one structure, use convenient maintenance, stable performance, high reliability, long service life, can work for 24 hours. The laser power by software control, frequency adjustable, equipment manufacturing cost is low, no consumables, power supply power consumption is small, high efficiency.
Applications
Leather clothes, furniture, epoxy resin, acrylic, craftwork gifts;
Widely used in paper, wood, gifts, food, packaging, etc.
Specification:
| Power | 30W,60W, 100W |
| Laser wavelength | 10.64um |
| Power adjustment range | 10-100% |
| Repetition frequency | ≤20KHz |
| Output beam quality | <1.8m² |
| Marking linear depth | 0.01-3.0mm |
| Minimum line width | 0.1mm |
| Min. Character size | 0.4mm |
| Repetition accuracy | ±0.01mm |
| Max. Liner marking speed | 7000mm/s |
| Marking format | PLT, DXF, CDR, AI, DWG, etc. |
| Software | EZCAD |
| Standard marking area |
30W 110×110mm 60W 140×140mm 100W 210×210mm |
| Cutting thickness | 3mm @ loop=10～100 |
| Power consumed | <1.2KW |
| Electrical demand | 220V 10%/50Hz/4A |
| Cooling mode | Air-cooling |
| Control interface | USB |
| Laser module life | 15,000 hours |
| Computer | WIN7 |
| Machine Size & Weight |
Desktop: 800×620×1450mm 120Kg Split: 450×420×560mm 45Kg |
| Usage environment | Clean,no shaking |
