Features:
1.
Excellent light quality:
Comparing with traditional solid laser marking machine, angle of divergence is only 1/4 of diode pump laser device. It is especially suitable for precision marking.
2. Low usage cost:
Photo electric conversion efficiency max is 30%, whole machine power consumption is less than 500W, it is the 1/10 of laser pump lamp marking machine. It greatly saves the cost in power consumption.
3. Free maintenance & long service life:
Using laser diode as the source of pump, full sealing light path design, its average no-failure operation is over 100 thousand hours.
4. Fast process speed:
Its processing speed is 5-10 times faster than traditional laser marking machine.
Application :
Metal Industry, Jewelry Factories, Hardware Tools, Electronics Components, Auto Parts, Mobile & Accessories, Clock&Watches, Planting Coating Materials, Spray Material, Plastic, Spectacles,etc.
Specification:
|
Laser wavelength |
1064nm |
|
Power adjustment range |
10-100% |
|
Repetition frequency |
20-80KHz |
|
Output beam quality |
<1.8m² |
|
Marking linear depth |
0.01-0.2mm |
|
Min. Spot diameter |
0.01mm |
|
Min. Character size |
0.1mm |
|
Repetition accuracy |
±0.02mm |
|
Max. Liner marking speed |
7000mm/s |
|
Control system |
Touch screen |
|
System Language |
English |
|
Standard marking area |
100×100mm |
|
Power consumed |
200W |
|
Electrical demand |
220V |
|
Cooling mode |
Air-cooling |
|
Total Weight |
6.8Kg |
|
Usage environment |
Clean,no shaking |
