Features:
1. Excellent light quality:Comparing with traditional solid laser marking machine, angle of divergence is only 1/4 of diode pump laser device. It is especially suitable for precision marking.
2. Low usage cost:
Photo electric conversion efficiency max is 30%, whole machine power consumption is less than 500W, it is the 1/10 of laser pump lamp marking machine. It greatly saves the cost in power consumption.
3. Free maintenance & long service life:
Using laser diode as the source of pump, full sealing light path design, its average no-failure operation is over 100 thousand hours.
4. Fast process speed:
Its processing speed is 5-10 times faster than traditional laser marking machine.
Application :
Metal Industry, Jewelry Factories, Hardware Tools, Electronics Components, Auto Parts, Mobile & Accessories, Clock&Watches, Planting Coating Materials, Spray Material, Plastic, Rubber, Spectacles,etc.
Specification:
| Laser wavelength | 1064nm |
| Power adjustment range | 10-100% |
| Repetition frequency | 20-80KHz |
| Output beam quality | <1.8m² |
| Marking linear depth | 0.01-0.2mm |
| Min. Spot diameter | 0.01mm |
| Min. Character size | 0.1mm |
| Repetition accuracy | ±0.02mm |
| Max. Liner marking speed | 7000mm/s |
| Marking format | PLT, DXF, CDR, AI, DWG, etc. |
| Software | EZCAD |
| Standard marking area |
20W 100×100mm 30W 100×100mm |
| Power consumed | <500W |
| Electrical demand | 220V 10%/50Hz/4A |
| Cooling mode | Air-cooling |
| Control interface | USB |
Software: EZCAD
| True Type Fonts | Single Stroke Fonts | Elliptical Text |
| Sequential Serial Numbers | Customizable Auto Dating | Barcodes |
| QR Codes and Data Matrix | UID Wizard | Logos |
| Images - JPG, TIF, GIF | CorelDraw, Adobe Illustrator | Raster Graphics |
| Vector Graphics | CAD Files |
Materials:
| Stainless Steel | Steel | Aluminum, Carbide |
| Nickel | Titanium | Cast Iron |
| Chrome | Painted Metal Alloys | Multi-Coated Metals |
| Plastics/Rubber | Backlit Buttons | Polycarbonate |
| PVC | Composites | Many more materials |
* Top 5 Laser Company in China
* Hold ISO 9001:2015, CE, SGS, FDA
* Sold 4500 units per year
* Served more than 10000 customers
* Recruiting distributor
* Share technical data to teach you how to connect machine with PLC or automation line
