6. It is equipped with a gas protection system, it effectively protects the product from argon gas during the welding process, maintains the original color of the product and ensures the welding quality.
Features:
1.The energy density is high, the heat input is low, the amount of thermal deformation is small, and the melting zone and the heat-affected zone are narrow and deep.
2.High cooling rate, which can weld fine weld structure and good joint performance.
3.Compared with contact welding, laser welding eliminates the need for electrodes, reducing daily maintenance costs and greatly increasing work efficiency.
4.The weld seam is thin, the penetration depth is large, the taper is small, the precision is high, the appearance is smooth, flat and beautiful.
5.No consumables, small size, flexible processing, low operating and maintenance costs.
Application
Suitable for large mold repairing and welding, mobile phone communications, jewelry crafts, electronic components, clocks, sensors, precision machinery, hardware, gas and vehicle parts, various metals and alloys parts, etc.
Technology parameters
|
Laser power |
1500W |
|
Center wavelength |
1080nm |
|
Output power stability |
＜3% |
|
Laser frequency |
50Hz-5KHz |
|
Adjustable power range |
10-100% |
|
Beam quality |
1.1 |
|
Optimal operating environment |
Temperature 0-40 ° C, humidity 20% -80% |
|
Electricity demand |
AC220V |
|
Output fiber length |
10m |
|
Cooling method |
Chiller |
|
Total power |
7kw |
