Product overview

Our core advantages:

1) Top 5 laser company in China. Sold 4500 units of laser machines in China market per year, with best price.
2) Usually have 50 units of laser marking machine(Fiber, CO2, UV, Mopa) in stock, lead time 3-5 days.
3) Fiber Laser cutting machine, (1000W-20,000W laser cutter), usually sell 50 units/month in China.
We are looking for distributor. Price is more competitive.
We have 250MB videos and manual reference, if you want, we can send you for free, please leave message.
Product Description

The third-generation single-module continuous fiber laser developed by Raycus Laser covers 250W to 2000W. The new generation laser has higher photoelectric conversion efficiency (>30%), better and more stable beam quality, and more powerful anti-high anti-reflection. The ability to introduce an optimized second-generation fiber optic transmission system to ensure a more stable and precise cutting effect in thick plate cutting. The product is suitable for a variety of applications: cutting, welding, drilling, medical device processing, etc., the cut sheet is narrow and the section is bright, which is obvious compared with other similar lasers in the market.

Features Good compatibility :

Can adapt to a number of manufacturers 80W sealed off CO2 laser tube, but also has strong adaptability and fast response,
engraving, cutting benefits good effect.

Control is simple:

Select high or low level control, the use of TTL-level control of the laser can start and stop. At the same
time increase the protection switch, testing is through the external water and ventilation.

Protection Function:

Power supply itself has open circuit protection, a good grounding in the case of protection, the power
supply to short-term work in the open state, so to avoid the laser tube burst due to the damage caused by laser power supply,
thereby enhancing the laser power supply of life.

Basic info

Average output power	1000W-20000W
output power stability	<3%
Terminal type	QBH
power supply(vac@50Hz/60Hz)	340-420,There Phase-four wire connect
Control Mode	ADRS232/AD
power consumption(W)	5500
Cooling	water cooling

Specification

The main parts are: Raycus source, IPG source, scanhead, control card, Rotary, XYZ working table, Lifting, Protective eyewear, Field lens.
1. Laser source: Raycus-20w,30w,50w,100w; IPG-20w,30w,50w; Synrad CO2 source-30w, 60w.
2. Scanhead: Spot size-10mm
3. Rotary device: 80mm
4. Working table: XY or XYZ
5. Control card: V2, V4
6. Field lens: f=100(80*80mm), f=160(100*100mm), f=210(150*150mm), f=254(180*180mm),
f=380(250*250mm),f=420(300*300mm)
7. Protective eyewear: 1064nm
8. Power supply: 5V(for control card), 15V(for Scanhead), 24V(for laser source)
9. Red light lens & Red light part.
10. Machine box: Desktop style, Split style, Portable style, Hand-held style.
11. Lifting: 50cm, 80cm, 100cm
